Design
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Product colour: Black
Fan location: Top
Cooling type: Active
Power
Max output current (+3.3V): 20 A
Combined power (+5V): 105 W
Combined power (-12V): 3.6 W
AC input frequency: 50 - 60 Hz
Combined power (+12V): 480 W
Power protection features: Short circuit, Over voltage, Overheating, Under voltage, Over current, Over power
AC input voltage: 100 - 240 V
Input current: 7 A
Combined power (+5Vsb): 15 W
Combined power (+3.3V): 105 W
Max output current (+12V): 40 A
Max output current (+5V): 20 A
Total power: 500 W
Max output current (+5Vsb): 3 A
Maximum input current (@110V): +12V,+3.3V,+5V,+5Vsb,-12V
Max output current (-12V): 0.3 A
Weight & dimensions
Height: 63 mm
Width: 125 mm
Depth: 130 mm
Performance
Power supply unit (PSU) form factor: SFX
80 PLUS certification: 80 PLUS Gold
Purpose: PC
Packaging data
Package weight: 1.8 kg
Manual: Yes
Package depth: 190 mm
Package height: 80 mm
Package width: 230 mm
Ports & interfaces
PCI Express power connectors (6+2 pin): 2
Number of SATA power connectors: 4
Floppy disk drive connector: Yes
Motherboard power connector: 20+4 pin ATX
Cabling type: Fully-Modular
Peripheral (Molex) power connectors (4-pin): 2
CPU power connector (4+4 pin): Yes
Other features
Case colour: Black
Housing colour: Black
Logistics data
Harmonized System (HS) code: 84733020
