Features
SmartStart function: Yes
Housing material: Plastic
Maximum indoor range: 40 m
Cable section: 0,5 - 1,5 mm²
Remotely operated: Yes
Technology: Z-Wave 800 LR Series
Type: Smart switch
Z-Wave™ frequency bands: 868,4 MHz; 865,2 MHz; 869,0 MHz; 921,4 MHz; 908,4 MHz; 916 MHz; 919,8 MHz; 922,5 MHz; 919,7-921,7-923,7 MHz; 868,1 MHz; 920,9 MHz
Built-in display: No
Product colour: Blue
Number of modules: 1
Connectivity technology: Wireless
Mounting type: Wall
Suitable for indoor use: Yes
Protection against overheating: Yes
Power
AC input frequency: 50/60 Hz
Power consumption (typical): 0.3 W
Maximum load power (AC): 2000 W
Maximum switching current (DC): 5 A
Maximum switching voltage (AC): 240 V
AC input voltage: 110 - 240 V
Maximum switching current (AC): 8 A
Maximum switching voltage (DC): 30 V
Operational conditions
Operating relative humidity (H-H): 30 - 70%
Operating temperature (T-T): -20 - 40 °C
Weight & dimensions
Weight: 19 g
Height: 29 mm
Depth: 16 mm
Width: 35 mm
Packaging data
Quantity per pack: 1 pc(s)
Package type: Box
