Technical details
Compliance certificates: Federal Communications Commission (FCC), CB, cTUVus, VCCI, RoHS, CE, UKCA, BSMI, RCM
Processor
Processor boost frequency: 4.5 GHz
Processor model: i3-1315U
Processor threads: 8
Built-in processor: Yes
Processor manufacturer: Intel
Processor cache: 10 MB
Processor cores: 6
Processor family: Intel® Core™ i3
Performance cores: 2
Efficient-core Max Turbo Frequency: 3.3 GHz
Performance-core Max Turbo Frequency: 4.5 GHz
Efficient cores: 4
Graphics
On-board graphics card model: Intel® UHD Graphics
Graphics card family: Intel
On-board graphics card: Yes
Number of displays supported: 3
Memory
Memory channels: Dual-channel
Maximum internal memory: 96 GB
ECC: No
Supported memory types: DDR5-SDRAM
Memory slots type: SO-DIMM
Supported memory clock speeds: 4800
Number of memory slots: 2
Non-ECC: Yes
Memory voltage: 1.1 V
Design
Cooling type: Passive
VESA mounting: Yes
Cable lock slot type: Kensington
Product type: All-in-One PC barebone
LED indicators: Power, SSD
Chassis type: All-in-One
Panel mounting interface: 100 x 100 mm
Cable lock slot: Yes
Product colour: Black
Power
Power supply type: External AC adapter
AC adapter output current: 4.74 A
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power supply: 90 W
Number of power supply units: 1
AC adapter output voltage: 19 V
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Height: 272.5 mm
Package weight: 4.5 kg
Weight: 3.25 kg
Width: 393.6 mm
Depth: 39.8 mm
Network
LAN controller: Intel I219V
Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11a
Bluetooth version: 4.2
Bluetooth: Yes
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
WLAN controller model: Realtek RTL8821CE
Performance
BIOS type: AMI EEPROM
Trusted Platform Module (TPM): Yes
Trusted Platform Module (TPM) version: 2.0
Processor socket: LGA 1700
Number of processors supported: 1
Built-in camera: Yes
Motherboard chipset: Intel SoC
Audio chip: Realtek ALC888S
Packaging content
Quick start guide: Yes
Power cord included: Yes
Drivers included: Yes
AC adapter included: Yes
Expansion slots
Number of M.2 (M) slots: 2
Display
Touchscreen: Yes
Display brightness: 250 cd/m²
Aspect ratio: 16:9
Display diagonal: 39.6 cm (15.6")
Panel type: IPS
Display resolution: 1920 x 1080 pixels
HD type: Full HD
Software
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Linux operating systems supported: Yes
Audio
Number of speakers: 2
RMS rated power: 2 W
Built-in speaker(s): Yes
Storage
Storage drive interface: PCI Express
Storage drive sizes supported: M.2
Supported storage drive types: SSD
SSD form factor: M.2
NVMe: Yes
Ports & interfaces
Microphone in: Yes
DC-in jack: Yes
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Headphone outputs: 1
COM ports quantity: 2
HDMI version: 2.0b
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Logistics data
Harmonized System (HS) code: 84714100
Sustainability
Sustainability certificates: ENERGY STAR
