Technical details
Compliance certificates: RoHS, CE, VCCI, RCM, Federal Communications Commission (FCC), BSMI, ETL, CB
Processor
Built-in processor: No
Graphics
On-board graphics card: Yes
Memory
Maximum internal memory: 96 GB
Number of memory slots: 2
Non-ECC: Yes
Supported memory clock speeds: 5600
ECC: No
Memory voltage: 1.1 V
Supported memory types: DDR5-SDRAM
Memory slots type: SO-DIMM
Memory channels: Dual-channel
Internal memory installed: No
Design
LED indicators: HDD, Power
Cable lock slot type: Kensington
VESA mounting: Yes
Panel mounting interface: 75 x 75,100 x 100 mm
On/off switch: Yes
Product type: Mini PC barebone
Product colour: Black
Cooling type: Active
Housing material: Metal
Chassis type: 1.35L sized PC
Cable lock slot: Yes
Power
AC input frequency: 50/60 Hz
Power supply: 120 W
AC adapter output current: 6.32 A
AC input voltage: 100 - 240 V
Number of power supply units: 1
AC adapter output voltage: 19 V
Power supply type: External AC adapter
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 50 °C
Weight & dimensions
Depth: 190 mm
Width: 165 mm
Weight: 1.3 kg
Package weight: 2.1 kg
Height: 43 mm
Network
Ethernet LAN: Yes
LAN controller: Intel I226, Intel I219V
Wi-Fi: No
Performance
Number of processors supported: 1
Trusted Platform Module (TPM): Yes
Processor socket: LGA 1700
Trusted Platform Module (TPM) version: 2.0
Motherboard chipset: Intel H610
Audio chip: Realtek ALC888S
BIOS type: AMI
Packaging content
Power cord included: Yes
Drivers included: Yes
Quick start guide: Yes
AC adapter included: Yes
Software
Windows operating systems supported: Windows 10, Windows 11
Linux operating systems supported: Yes
Audio
Built-in speaker(s): No
Storage
Supported storage drive types: HDD & SSD
Storage drives installed: No
Storage drive sizes supported: 2.5, M.2
NVMe: Yes
Ports & interfaces
HDMI version: 2.0b
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
DC-in jack: Yes
HDMI ports quantity: 1
Headphone outputs: 1
Ethernet LAN (RJ-45) ports: 2
DisplayPorts quantity: 2
DisplayPort version: 1.4
USB 2.0 ports quantity: 4
Serial ports quantity: 2
Microphone in: Yes
Sustainability
Sustainability certificates: ENERGY STAR, ErP
