Technical details
Compliance certificates: UKCA, CB, Federal Communications Commission (FCC), cTUVus, BSMI, RoHS, CE, VCCI, RCM
Processor
Built-in processor: No
Processor manufacturer: Intel
Graphics
On-board graphics card: Yes
Memory
Supported memory types: DDR5-SDRAM
Memory slots type: SO-DIMM
Number of memory slots: 2
Memory channels: Dual-channel
Memory voltage: 1.1 V
Non-ECC: Yes
Supported memory clock speeds: 5600
Maximum internal memory: 64 GB
Design
On/off switch: Yes
Chassis type: Desktop
Product type: PC barebone
LED indicators: Yes
Cooling type: Active
Product colour: Black
Power
Power supply: 180 W
Power supply type: External AC adapter
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
AC adapter output current: 9.23 A
AC adapter output voltage: 19.5 V
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 50 °C
Weight & dimensions
Depth: 200 mm
Height: 95 mm
Width: 250 mm
Package weight: 3.49 kg
Weight: 2.98 kg
Network
Wi-Fi: No
Ethernet LAN: Yes
LAN controller: Intel I226-LM, Intel® I219-LM
Performance
Processor socket: LGA 1700
BIOS type: UEFI AMI
Audio output channels: 7.1 channels
Trusted Platform Module (TPM) version: 2.0
Motherboard chipset: Intel H610
Trusted Platform Module (TPM): Yes
Number of processors supported: 1
Audio chip: Realtek ALC888S
Packaging content
Power cord included: Yes
Drivers included: Yes
Quick start guide: Yes
AC adapter included: Yes
Software
Linux operating systems supported: Yes
Windows operating systems supported: Windows 11
Audio
Built-in speaker(s): No
Storage
Storage drive interface: PCI Express, Serial ATA III
NVMe: Yes
Storage drive sizes supported: M.2, 2.5
Supported storage drive types: HDD & SSD
Ports & interfaces
HDMI version: 2.0b
Headphone outputs: 1
USB 2.0 ports quantity: 4
Microphone in: Yes
DisplayPort version: 1.4
DC-in jack: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
DisplayPorts quantity: 1
HDMI ports quantity: 2
Ethernet LAN (RJ-45) ports: 2
Other features
Country of origin: China
Logistics data
Harmonized System (HS) code: 84733080
Sustainability
Sustainability certificates: ENERGY STAR, ErP
