Technical details
Compliance certificates: VCCI, CB, cTUVus, RCM, Federal Communications Commission (FCC), RoHS, CE, BSMI
Processor
Processor boost frequency: 4.6 GHz
Processor family: Intel® Core™ i5
Performance-core boost frequency: 4.6 GHz
Efficient-core boost frequency: 3.4 GHz
Processor generation: 13th gen Intel® Core™ i5
Efficient cores: 8
ECC supported by processor: No
Processor cache: 12 MB
Thermal Design Power (TDP): 15 W
Performance cores: 2
Processor manufacturer: Intel
Processor threads: 12
Processor model: i5-1335U
Processor cores: 10
Built-in processor: Yes
Graphics
On-board graphics card model: Intel® UHD Graphics
Graphics card family: Intel
On-board graphics card: Yes
Memory
Supported memory clock speeds: 5200
Maximum internal memory: 64 GB
Internal memory installed: No
Number of memory slots: 2
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Memory slots type: SO-DIMM
Memory voltage: 1.1 V
Design
LED indicators: HDD, Power
Cable lock slot: Yes
Product colour: Black
On/off switch: Yes
Panel mounting interface: 75 x 75,100 x 100 mm
Cooling type: Passive
VESA mounting: Yes
Product type: Mini PC barebone
Chassis type: 1.3L sized PC
Cable lock slot type: Kensington
Housing material: Steel
Power
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
AC adapter output current: 1.6 A
AC adapter output voltage: 19 V
Power supply: 90 W
Power supply type: External AC adapter
Number of power supply units: 1
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Package weight: 2.3 kg
Weight: 1.6 kg
Height: 39.5 mm
Width: 200 mm
Depth: 165 mm
Network
LAN controller: Intel® I219, Intel I226-LM
Ethernet LAN: Yes
Wi-Fi: No
Performance
Trusted Platform Module (TPM): Yes
Audio chip: Realtek ALC888S
Number of processors supported: 1
BIOS type: UEFI AMI
Trusted Platform Module (TPM) version: 2.0
Packaging content
Quick start guide: Yes
AC adapter included: Yes
Power cord included: Yes
Software
Windows operating systems supported: Windows 11, Windows 10
Operating system installed: No
Linux operating systems supported: Yes
Audio
Built-in speaker(s): No
Storage
Supported storage drive types: HDD & SSD
Number of storage drives supported: 3
Storage drive sizes supported: 2.5, M.2
NVMe: Yes
Storage drive interface: PCI Express, Serial ATA III
Storage drives installed: No
Ports & interfaces
DC-in jack: Yes
USB 2.0 ports quantity: 2
DisplayPorts quantity: 1
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Headphone outputs: 1
VGA (D-Sub) ports quantity: 1
Microphone in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI ports quantity: 1
HDMI version: 2.0b
Serial ports quantity: 1
Logistics data
Harmonized System (HS) code: 84733080
Sustainability
Sustainability certificates: ENERGY STAR, ErP
Sustainability compliance: Yes
