Design
Product colour: Black
Mounting: Desk/Wall
Product type: IP Phone
Device lock: Yes
Handset type: Wired handset
Power
Power over Ethernet (PoE): Yes
AC adapter output voltage: 5 V
Power consumption (typical): 10 W
Operational conditions
Operating temperature (T-T): 0 - 35 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -10 - 45 °C
Management features
Volume control: Digital
Number of programmable keys: 12
Weight & dimensions
Weight: 900 g
Height: 135 mm
Depth: 200 mm
Width: 250 mm
Network
Bluetooth: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Ethernet LAN interface type: Gigabit Ethernet
Wi-Fi: No
Ethernet LAN: Yes
Supported network protocols: DHCP, HTTP, NTP, LDAP, TFTP, HTTPS
Performance
Dual-Tone Multi-Frequency (DTMF) modes: In-band, SIP info, Out-of band
Packaging content
Quick start guide: Yes
Manual: Yes
Number of handles included: 1 pc(s)
Display
Display: TFT
Display diagonal: 10.9 cm (4.3")
Backlight display: Yes
Touchscreen: No
Audio
Voice codecs: G.729ab, G.722, G.711a, G.726, G.711Mu
Microphone mute: Yes
Speakerphone: Yes
Comfort noise generation (CNG): Yes
Certification: CE, FCC
Certificates
Safety: IEC 60950, CB
Ports & interfaces
USB 2.0 ports quantity: 1
Ethernet LAN (RJ-45) ports: 2
Camera
Front camera: No
Logistics data
Harmonized System (HS) code: 85171800
Video
Video call: No
Phone features
Call waiting: Yes
Caller ID: Yes
Call hold: Yes
Conference call: Yes
Answering machine: Yes
Speed dialling: Yes
Short Message Service (SMS): Yes
Phonebook capacity: 1000 entries
Call pick up: Yes
Call park: Yes
Call forwarding: Yes
Lines quantity: 12 lines
Redialing: Yes
Do not disturb function: Yes
Call history: Yes
Call transfer: Yes
