Purpose: Photovoltaic panels
Features
Charging method: CC-CV-FL
Power protection features: Under voltage, Battery discharge, Overvoltage protection, Over voltage, Overcharge, Overheating, Overvoltage protection
Product colour: Red, Black
Supported battery type: AGM / Gel / LiFePO
Power current type: DC
MPPT function: Yes
International Protection (IP) code: IP21
Design
Cooling type: Active
Safety shutter: Yes
Built-in display: Yes
RS485 port: Yes
Conductor cross section (max): 20 mm²
Display type: LCD
Power
Input voltage: 12V / 24V / 36V / 48V - auto-detection
Total power: 12V - 390W, 24V - 780W, 48V - 1560W, 36V - 1170W
Power supply voltage: 12 - 150 VDC
Maximum charging current: 30 A
Charging voltage: 12V: 9V-15V / 24V: 18V-30V / 36V: 32V-40V / 48V: 42V-60V
Output current: 40 A
Weight & dimensions
Weight: 1.8 kg
Depth: 250 mm
Width: 170 mm
Height: 66 mm
Performance
Operating temperature (T-T): -20 - 55 °C
Noise level: 40 dB
Temperature compensation: -3mV/°/2V
Packaging content
Mounting brackets included: Yes
Cables included: USB cable
Temperature sensor: Yes
Screwdriver included: Yes
