Safety warning: Installation and service only by qualified electrician; disconnect from mains before opening; follow manuals
Technical details
Package volume: 43500 cm³
Pallet gross volume: 2016 dm³
Pallet gross weight: 180 kg
Safety notices link: https://www.stag-ev.com
Dispose of contents/container to (P501): Dispose of equipment as WEEE and packaging via appropriate recycling streams
PSTI certified: No
Compliance certificates: RoHS, Electromagnetic Compatibility (EMC)
Pallet net weight: 120 kg
Pallet net width: 80 cm
Total carbon footprint (kg of CO2e): n/a (no product‑level CFP published)
Pallet net length: 120 cm
Product supplier data: Brand: STAGEV; Manufactured: AC S.A., Address: ul. 42 Pułku Piechoty 50, 15‑181 Białystok, Poland; Website: www.stag-ev.com
Warranty period: 3 year(s)
Pallet net height: 2.1 m
Dangerous goods: No
Recycling codes: PELD/LDPE (Low-density polyethylene), PAP (Corrugated fiberboard (cardboard)
Compatible products: EV/PHEV compliant with IEC 61851‑1 using Type 2 AC charging
Features
Built-in display: Yes
Touchscreen: Yes
Display type: LCD
Suitable for: Outdoor
Bluetooth: No
Charging voltage: 230/400 V AC (L-N / L-L), 3-phase
Product colour: Graphite, White
Power cable length: 5 m
Housing material: Glass, Polycarbonate (PC)
Socket type: Type 2
Handle(s): Yes
Number of phases: 3
AC input frequency: 50–60
On/off switch: No
Mounting type: Wall
Wi-Fi: Yes
Charging current: 16 A
International Protection (IP) code: IP65
AC input voltage: 230/400 V AC (L-N / L-L), 3-phase
Input current: 16 A
Output current: 32 A
Cable entry location: Bottom, Rear
Fault diagnose system: Yes
Output power: 22 kW
Charging cable length: 5 m
Weight & dimensions
Weight: 2.5 kg
Width: 230 mm
Height: 390 mm
Depth: 125 mm
Package weight: 3.7 kg
Package depth: 510 mm
Package height: 275 mm
Package width: 310 mm
Certificates
UN number: Not applicable / not classified as dangerous good
Logistics data
Country of origin: Poland
Export Control Classification Number (ECCN): EAR99
Customs product code (TARIC): 8537109170
Safety warning
Hazard pictogram(s): GHS05: Corrosive, GHS04: Compressed gas
Warnings: Before use, make sure the device is correctly installed by a qualified electrician., Disconnect the unit from the power supply during maintenance or servicing., Do not use the unit in a damp or wet environment to avoid the risk of electric shock.
