Safety warning: Installation and service only by qualified electrician; disconnect from mains before opening; follow manuals
Technical details
Recycling codes: PELD/LDPE (Low-density polyethylene), PAP (Corrugated fiberboard (cardboard)
Safety notices link: https://www.stag-ev.com
Product supplier data: Brand: STAGEV; Manufactured: AC S.A., Address: ul. 42 Pułku Piechoty 50, 15‑181 Białystok, Poland; Website: www.stag-ev.com
PSTI certified: No
Compliance certificates: RoHS, Electromagnetic Compatibility (EMC)
Compatible products: EV/PHEV compliant with IEC 61851‑1 using Type 2 AC charging
Features
Touchscreen: Yes
Charging voltage: 230/400 V AC (L-N / L-L), 3-phase
International Protection (IP) code: IP65
Wi-Fi: Yes
Charging current: 16 A
Handle(s): Yes
Housing material: Glass, Polycarbonate (PC)
Built-in display: Yes
Power cable length: 5 m
Suitable for: Outdoor
Display type: LCD
Output power: 11 kW
AC input frequency: 50–60
On/off switch: No
Mounting type: Wall
Product colour: White, Graphite
AC input voltage: 230/400 V AC (L-N / L-L), 3-phase
Bluetooth: No
Fault diagnose system: Yes
Number of phases: 3
Socket type: Type 2
Input current: 16 A
Cable entry location: Bottom, Rear
Output current: 16 A
Charging cable length: 5 m
Weight & dimensions
Package height: 275 mm
Package width: 310 mm
Width: 230 mm
Package weight: 3.7 kg
Height: 390 mm
Package depth: 510 mm
Weight: 2.5 kg
Depth: 125 mm
Certificates
UN number: Not applicable / not classified as dangerous good
Logistics data
Country of origin: Poland
Export Control Classification Number (ECCN): EAR99
Customs product code (TARIC): 8537109170
Safety warning
Hazard pictogram(s): GHS05: Corrosive, GHS04: Compressed gas
Warnings: Before use, make sure the device is correctly installed by a qualified electrician., Do not use the unit in a damp or wet environment to avoid the risk of electric shock., Disconnect the unit from the power supply during maintenance or servicing.
