Safety warning: Installation and service only by qualified electrician; disconnect from mains before opening; follow manuals
Technical details
Recycling codes: PAP (Corrugated fiberboard (cardboard), PELD/LDPE (Low-density polyethylene)
Safety notices link: https://www.stag-ev.com
PSTI certified: No
Compliance certificates: Electromagnetic Compatibility (EMC), RoHS
Product supplier data: Brand: STAGEV; Manufactured: AC S.A., Address: ul. 42 Pułku Piechoty 50, 15‑181 Białystok, Poland; Website: www.stag-ev.com
Compatible products: EV/PHEV compliant with IEC 61851‑1 using Type 2 AC charging
Features
Touchscreen: Yes
Housing material: Glass, Polycarbonate (PC)
Handle(s): Yes
Charging voltage: 230/400 V AC (L-N / L-L), 3-phase
Bluetooth: No
Built-in display: Yes
Suitable for: Outdoor
Wi-Fi: Yes
Charging current: 16 A
Socket type: Type 2
Product colour: White, Graphite
Mounting type: Wall
AC input voltage: 230/400 V AC (L-N / L-L), 3-phase
Power cable length: 5 m
International Protection (IP) code: IP65
Display type: LCD
AC input frequency: 50–60
On/off switch: No
Input current: 16 A
Number of phases: 3
Output current: 16 A
Cable entry location: Bottom, Rear
Output power: 11 kW
Fault diagnose system: Yes
Charging cable length: 5 m
Weight & dimensions
Height: 390 mm
Width: 230 mm
Package weight: 3.7 kg
Package width: 310 mm
Package depth: 510 mm
Package height: 275 mm
Depth: 125 mm
Weight: 2.5 kg
Certificates
UN number: Not applicable / not classified as dangerous good
Logistics data
Country of origin: Poland
Export Control Classification Number (ECCN): EAR99
Customs product code (TARIC): 8537109170
Safety warning
Hazard pictogram(s): GHS04: Compressed gas, GHS05: Corrosive
Warnings: Disconnect the unit from the power supply during maintenance or servicing., Do not use the unit in a damp or wet environment to avoid the risk of electric shock., Before use, make sure the device is correctly installed by a qualified electrician.
