Processor
Processor socket: LGA 4677 (Socket E)
Processor manufacturer: Intel
Compatible processor series: Intel® Xeon®
Features
Motherboard chipset: Intel C741
Motherboard chipset family: Intel
Motherboard form factor: Extended ATX
Component for: Server
Memory
Supported memory clock speeds: 5600, 4400, 4000, 4800
Maximum internal memory: 4 TB
Supported memory module capacities: 256MB, 16GB, 64GB, 128GB, 32GB
Maximum RDIMM memory: 256 GB
Supported memory types: DDR5-SDRAM
Number of memory slots: 16
Memory voltage: 1.1 V
ECC сompatibility: ECC
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 8 - 90%
Operating temperature (T-T): 10 - 35 °C
Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
Depth: 332.7 mm
Width: 307.3 mm
Network
LAN controller: Broadcom BCM57416
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: 10 Gigabit Ethernet
Internal I/O
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Power fan connector: Yes
Number of SATA III connectors: 8
Number of COM connectors: 1
TPM connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
BIOS
System Management BIOS (SMBIOS) version: 3.5
ACPI version: 6.4
BIOS type: UEFI AMI
Storage controllers
Supported storage drive interfaces: SATA III
RAID levels: 10, 5, 1, 0
RAID support: Yes
Rear panel I/O ports
USB 2.0 ports quantity: 4
COM ports quantity: 1
VGA (D-Sub) ports quantity: 1
Ethernet LAN (RJ-45) ports: 2
Expansion slots
PCI Express x16 (Gen 5.x) slots: 5
PCI Express x8 slots: 1
