Processor
Processor socket: LGA 1700
Processor manufacturer: Intel
Compatible processor series: Intel Pentium G, Intel® Xeon®
Features
Component for: Server
Motherboard chipset: Intel C262
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Memory
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory voltage: 1.1 V
Number of memory slots: 4
ECC сompatibility: ECC
Supported memory clock speed (max): 4400 MHz
Supported memory module capacities: 16GB, 32GB, 8GB
Maximum internal memory: 128 GB
Supported memory clock speeds: 4000, 4400, 3600
Unbuffered memory: Yes
Operational conditions
Operating relative humidity (H-H): 8 - 80%
Storage relative humidity (H-H): 8 - 90%
Operating temperature (T-T): -5 - 55 °C
Storage temperature (T-T): -30 - 60 °C
Network
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Internal I/O
TPM connector: Yes
Number of COM connectors: 1
Number of SATA III connectors: 8
USB 2.0 connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
BIOS
System Management BIOS (SMBIOS) version: 3.5
BIOS memory size: 32 Mbit
ACPI version: 6.4
BIOS type: UEFI AMI
Storage controllers
RAID levels: 0, 1, 10, 5
RAID support: Yes
Supported storage drive interfaces: SATA III
Rear panel I/O ports
COM ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
VGA (D-Sub) ports quantity: 1
USB 2.0 ports quantity: 2
Ethernet LAN (RJ-45) ports: 2
Expansion slots
PCI Express x4 (Gen 4.x) slots: 2
PCI Express x8 (Gen 5.x) slots: 2
Number of M.2 (M) slots: 1
