Design
Product colour: Black
Reset button: Yes
LED indicators: Yes
Rack mounting: No
Housing material: Metal
Power
Input current: 2.22 A
DC input voltage: 54 V
Power consumption (max): 110 W
Redundant power supply (RPS) support: Yes
Power source: DC/PoE
Power supply included: Yes
Security
DHCP features: DHCP client
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Management features
Web-based management: Yes
Switch type: Managed
Quality of Service (QoS) support: Yes
Cloud-managed: Yes
Switch layer: L2
Weight & dimensions
Weight: 500 g
Height: 30 mm
Depth: 106 mm
Width: 190 mm
Network
Ethernet LAN data rates: 10,100,1000 Mbit/s
Networking standards: IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u, IEEE 802.3bt, IEEE 802.3at
Number of VLANs: 32
Virtual LAN features: Port-based VLAN
VLAN support: Yes
Copper ethernet cabling technology: 100BASE-TX, 1000BASE-T, 10BASE-T
Flow control support: Yes
10G support: No
Packaging data
Package weight: 1.25 kg
Package depth: 244 mm
Package height: 87 mm
Package width: 256 mm
Certificates
Compliance certificates: CE
Ports & interfaces
Fast Ethernet (copper) ports quantity: 8
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Gigabit Ethernet (copper) ports quantity: 2
Data transmission
Switching capacity: 5.6 Gbit/s
MAC address table: 8000 entries
Forwarding rate: 4.17 Mpps
Packet buffer memory: 0.5 MB
Jumbo frames support: Yes
Jumbo frames: 9216
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 8
Power over Ethernet (PoE): Yes
Safety warning
Warnings: Ensure the unit is adequately ventilated during operation., The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Do not open the case or try to repair it yourself.
Sustainability
Sustainability compliance: Yes
