Processor
Processor manufacturer: AMD
Processor model: V1500B
Processor cores: 4
Processor frequency: 2.2 GHz
Processor threads: 8
Processor family: Ryzen Embedded
Processor generation: AMD Ryzen Embedded V1000 Series
Memory
Internal memory type: DDR4
Memory slots: 2
Memory form factor: SO-DIMM
ECC: Yes
Internal memory: 8 GB
Maximum RAM supported: 32 GB
Design
Product colour: Black
Number of fans: 2 fan(s)
Fan diameter: 12 cm
Cooling type: Active
Fan diameter 2: 12 cm
LED indicators: Yes
Drive bay locking: Yes
Power
Power consumption (HDD standby): 18.34 W
AC input voltage: 100 - 240 V
Power consumption (typical): 60.1 W
AC input frequency: 50 - 60 Hz
Power supply unit (PSU) capacity: 250 W
Power supply location: External
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Height: 166 mm
Weight: 6 kg
Width: 343 mm
Depth: 243 mm
Network
Ethernet LAN data rates: 2500 Mbit/s
Ethernet LAN: Yes
Wake-on-LAN ready: Yes
Performance
Number of users: 1024 user(s)
On/off switch: Yes
Snapshot: Yes
Backup function: Yes
Noise level: 23.8 dB
Type: NAS
System log: Yes
Web-based management: Yes
Device class: Home & Home Office
Backup features: iSCSI LUN, Cloud
Multilingual support: Yes
Access Control List (ACL): Yes
Packaging content
Cables included: AC, LAN (RJ-45)
External power adapter: Yes
Power cables quantity: 1
Storage
RAID support: Yes
Hot-swap drive bays: Yes
Storage drive sizes supported: 2.5, 3.5", M.2
RAID levels: 0, 1, JBOD, 10, 6, 5
Number of storage drives supported: 18
Supported storage drive interfaces: M.2, Serial ATA
Number of M.2 (M & B) slots: 2
Supported storage drive types: HDD & SSD
Installed storage drive type: No
Supported file systems: FAT32, ext4, HFS+, exFAT, ext3, NTFS, BTRFS
Storage drives installed: No
Total installed storage capacity: 0 TB
Maximum supported storage capacity: 360 TB
Storage drive capacity: 0 GB
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB port: Yes
Ethernet LAN (RJ-45) ports: 2
Other features
Warranty period: 3 year(s)
Compliance certificates: RoHS
