Technical details
Sustainability certificates: UKCA, Federal Communications Commission (FCC), CE, CCC
Processor
Processor family: Realtek
Processor model: RTD1619B
Processor frequency: 1.7 GHz
Processor cores: 4
Processor manufacturer: Realtek
Memory
Maximum RAM supported: 6 GB
Internal memory: 2 GB
Internal memory type: DDR4
Design
Built-in speaker(s): No
Cooling type: Active
Built-in display: No
LED indicators: Yes
Cable lock slot: Yes
Product colour: Black
Fan diameter 2: 8 cm
Fan diameter: 8 cm
Cable lock slot type: Kensington
Number of fans: 2 fan(s)
Power
Power supply location: External
AC input frequency: 50 / 60 Hz
Redundant power supply (RPS) support: No
AC input voltage: 100 - 240 V
Power consumption (typical): 32.41 W
Power supply unit (PSU) capacity: 90 W
Number of power supply units: 1
Power consumption (sleep): 4.97 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -20 - 60 °C
Operating altitude: 0 - 5000 m
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Width: 184 mm
Depth: 168 mm
Height: 230 mm
Weight: 2.21 kg
Network
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
iSCSI support: Yes
Ethernet LAN: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T
Supported network protocols: SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Performance
Security algorithms: HTTPS, SSL/TLS, SSH, SSH-1.5, SSH-2
Backup features: iSCSI LUN, Cloud
Noise level: 22.9 dB
Access Control List (ACL): Yes
Multilingual support: Yes
Type: NAS
Reset button: Yes
Built-in FTP server: Yes
Card reader integrated: No
System log: Yes
Buzzer: Yes
On/off switch: Yes
Browser supported: Google Chrome, Firefox, Microsoft Edge, Safari
Number of users: 1024 user(s)
Device class: Home & Home Office
Backup function: Yes
Packaging content
Power cables quantity: 1
Cables included: LAN (RJ-45), AC
External power adapter: Yes
Software
Operating system installed: DiskStation Manager
Storage
Hot-swap drive bays: Yes
RAID levels: JBOD, 5, 6, 0, 10, 1
Supported file systems: FAT32, BTRFS, exFAT, HFS+, ext4, ext3, NTFS
Maximum supported storage capacity: 108 TB
RAID support: Yes
Supported storage drive types: HDD & SSD
Installed storage drive type: No
Storage drive sizes supported: 3.5", 2.5"
Number of M.2 (M & B) slots: 2
Storage drives installed: No
Number of storage drives supported: 4
Supported storage drive interfaces: Serial ATA
Storage drive size: 2.5/3.5"
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB port: Yes
