Processor
Processor generation: AMD Ryzen Embedded R1000 Series
Processor boost frequency: 3.1 GHz
Processor family: Ryzen Embedded
Processor frequency: 2.6 GHz
Processor cores: 2
Processor model: R1600
Processor threads: 4
Processor manufacturer: AMD
Memory
ECC: Yes
Memory form factor: SO-DIMM
Maximum RAM supported: 32 GB
Internal memory: 4 GB
Internal memory type: DDR4
Memory slots: 2
Design
Product colour: Black
LED indicators: Yes
Drive bay locking: Yes
Cooling type: Active
Fan diameter: 9.2 cm
Number of fans: 1 fan(s)
Power
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Power supply location: External
Power consumption (HDD standby): 7.87 W
Power supply unit (PSU) capacity: 65 W
Power consumption (typical): 20.41 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Weight: 1.51 kg
Width: 106 mm
Height: 166 mm
Depth: 223 mm
Network
Ethernet LAN data rates: 2500
Wake-on-LAN ready: Yes
Ethernet LAN: Yes
Performance
Web-based management: Yes
Type: NAS
On/off switch: Yes
Backup function: Yes
Noise level: 17.9 dB
Multilingual support: Yes
Backup features: Cloud, iSCSI LUN
Snapshot: Yes
System log: Yes
Access Control List (ACL): Yes
Number of users: 512 user(s)
Device class: Home & Home Office
Packaging content
Power cables quantity: 1
Cables included: AC, LAN (RJ-45)
External power adapter: Yes
Storage
RAID levels: 1, 0, 10, 5, 6, JBOD
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, Serial ATA
RAID support: Yes
Storage drives installed: No
Number of storage drives supported: 7
Supported file systems: ext4, HFS+, ext3, NTFS, exFAT, BTRFS, FAT32
Storage drive capacity: 0 GB
Maximum supported storage capacity: 140 TB
Installed storage drive type: No
Hot-swap drive bays: Yes
Storage drive sizes supported: 3.5", 2.5, M.2
Total installed storage capacity: 0 TB
Number of M.2 (M & B) slots: 2
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB port: Yes
Other features
Warranty period: 3 year(s)
Compliance certificates: RoHS
