Processor
Processor generation: AMD Ryzen Embedded V1000 Series
Processor cores: 4
Processor family: Ryzen Embedded
Processor model: V1500B
Processor threads: 8
Processor manufacturer: AMD
Processor frequency: 2.2 GHz
Memory
Memory slots: 2
ECC: Yes
Maximum RAM supported: 32 GB
Memory form factor: SO-DIMM
Internal memory: 4 GB
Internal memory type: DDR4
Design
Number of fans: 2 fan(s)
Drive bay locking: Yes
Cooling type: Active
Fan diameter: 9.2 cm
Fan diameter 2: 9.2 cm
LED indicators: Yes
Product colour: Black
Power
Power consumption (HDD standby): 12.33 W
AC input frequency: 50 - 60 Hz
Power supply location: External
Power supply unit (PSU) capacity: 100 W
Power consumption (typical): 37.91 W
AC input voltage: 100 - 240 V
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 5 - 95%
Weight & dimensions
Height: 166 mm
Depth: 223 mm
Weight: 2.26 kg
Width: 199 mm
Network
Ethernet LAN: Yes
Ethernet LAN data rates: 2500 Mbit/s
Supported network protocols: SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Wake-on-LAN ready: Yes
Performance
Number of users: 512 user(s)
Backup function: Yes
Device class: Home & Home Office
On/off switch: Yes
Access Control List (ACL): Yes
Snapshot: Yes
Browser supported: Chrome,Firefox,Edge,Safari
Backup features: iSCSI LUN, Cloud
Multilingual support: Yes
System log: No
Type: NAS
Noise level: 20.5 dB
Web-based management: Yes
Packaging content
External power adapter: Yes
Power cables quantity: 1
Cables included: LAN (RJ-45), AC
Storage
Storage drive sizes supported: 2.5, 3.5", M.2
Maximum supported storage capacity: 180 TB
Supported storage drive interfaces: M.2, Serial ATA
Supported file systems: BTRFS, HFS+, ext3, NTFS, exFAT, FAT32, ext4
Storage drive interface: M.2, Serial ATA
Storage drive capacity: 0 GB
Total installed storage capacity: 0 TB
RAID levels: JBOD, 1, 6, 10, 0, 5
Installed storage drive type: No
Number of storage drives supported: 9
Number of M.2 (M & B) slots: 2
Storage drives installed: No
Hot-swap drive bays: Yes
RAID support: Yes
Supported storage drive types: HDD & SSD
Ports & interfaces
USB port: Yes
Ethernet LAN (RJ-45) ports: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Certification: FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
BIS
Other features
Warranty period: 3 year(s)
Compliance certificates: RoHS
