Processor
Processor cores: 4
Processor manufacturer: AMD
Processor model: V1500B
Processor family: Ryzen Embedded
On-board graphics card model: Not available
Processor frequency: 2.2 GHz
Processor generation: AMD Ryzen Embedded V1000 Series
Memory
ECC: Yes
Memory slots: 2
Internal memory type: DDR4
Memory form factor: SO-DIMM
Maximum RAM supported: 32 GB
Internal memory: 4 GB
Design
Drive bay locking: Yes
Chassis type: Rack (2U)
Number of fans: 2 fan(s)
LED indicators: Status, HDD, Power
Cooling type: Active
Fan diameter: 8 cm
Product colour: Black
Power
AC input voltage: 100 - 240 V
Power supply location: Built-in
Power consumption (typical): 49.89 W
AC input frequency: 50 - 60 Hz
Power supply unit (PSU) capacity: 250 W
Power consumption (HDD standby): 22.64 W
Operational conditions
Operating temperature (T-T): 0 - 35 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -20 - 60 °C
Operating altitude: 0 - 5000 m
Weight & dimensions
Width: 482 mm
Weight: 6.9 kg
Depth: 306.6 mm
Height: 88 mm
Network
Wake-on-LAN ready: Yes
Ethernet LAN data rates: 1000 Mbit/s
Link aggregation: Yes
iSCSI support: Yes
Ethernet LAN: Yes
Load balancing system: Yes
Supported network protocols: SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN
Performance
Security algorithms: SSL/TLS, HTTPS, SSH
Access Control List (ACL): Yes
Share folder: AFP, CIFS/SMB, FTP, WebDAV
Noise level: 25.2 dB
On/off switch: Yes
Management protocols: SNMP
Device class: Small & Medium Business
Backup function: Yes
Type: NAS
Multilingual support: Yes
Backup features: Cloud, iSCSI LUN
Built-in FTP server: Yes
Web-based management: Yes
Browser supported: Safari, Chrome, Edge, Internet Explorer, Firefox
Reset button: Yes
Hot spare: Yes
System log: Yes
Snapshot: Yes
Packaging content
Cables included: AC
Power cables quantity: 2
Software
Mac operating systems supported: Yes
Windows operating systems supported: Yes
Operating system installed: DiskStation Manager
Storage
Storage drive sizes supported: 2.5, 3.5"
Installed storage drive type: No
RAID levels: 10, 6, 1, 0, 5, JBOD
Supported file systems: ext4, Fat, ext3, NTFS, HFS+, exFAT, BTRFS
Supported storage drive types: HDD & SSD
Total installed storage capacity: 0 TB
Online RAID expansion: Yes
Hot-swap drive bays: Yes
Storage drives installed: No
Storage drive capacity: 0 GB
Number of storage drives supported: 8
RAID support: Yes
Online RAID migration: Yes
Supported storage drive interfaces: Serial ATA II, Serial ATA III
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 4
USB port: Yes
PCI Express x8 (Gen 3.x) slots: 1
eSATA ports quantity: 1
Other features
Compliance certificates: RoHS, CE
Logistics data
Harmonized System (HS) code: 84714100
Sustainability
Sustainability compliance: Yes
