Processor
Processor cores: 4
On-board graphics card model: Not available
Processor frequency: 2.2 GHz
Processor family: Ryzen Embedded
Processor model: V1500B
Processor manufacturer: AMD
Processor generation: AMD Ryzen Embedded V1000 Series
Memory
ECC: Yes
Memory form factor: SO-DIMM
Maximum RAM supported: 32 GB
Internal memory: 4 GB
Internal memory type: DDR4
Memory slots: 2
Design
Cooling type: Active
LED indicators: Power, Status, HDD
Product colour: Black
Chassis type: Rack (2U)
Number of fans: 2 fan(s)
Fan diameter: 8 cm
Drive bay locking: Yes
Power
AC input voltage: 100 - 240 V
Redundant power supply (RPS) support: Yes
AC input frequency: 50 - 60 Hz
Power supply location: Built-in
Power supply unit (PSU) capacity: 350 W
Power consumption (HDD standby): 29.98 W
Power consumption (typical): 61.94 W
Operational conditions
Operating altitude: 0 - 5000 m
Operating temperature (T-T): 0 - 35 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 5 - 95%
Weight & dimensions
Weight: 11.7 kg
Width: 482 mm
Depth: 407.5 mm
Height: 88 mm
Network
Ethernet LAN data rates: 1000 Mbit/s
Wake-on-LAN ready: Yes
iSCSI support: Yes
Supported network protocols: SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN
Load balancing system: Yes
Ethernet LAN: Yes
Link aggregation: Yes
Performance
Reset button: Yes
Security algorithms: SSL/TLS, SSH, HTTPS
Type: NAS
Noise level: 40 dB
Web-based management: Yes
Browser supported: Safari, Chrome, Edge, Internet Explorer, Firefox
Device class: Small & Medium Business
Backup features: Cloud, iSCSI LUN
Multilingual support: Yes
Hot spare: Yes
System log: Yes
On/off switch: Yes
Snapshot: Yes
Management protocols: SNMP
Backup function: Yes
Access Control List (ACL): Yes
Share folder: AFP, CIFS/SMB, FTP, WebDAV
Built-in FTP server: Yes
Packaging content
Power cables quantity: 2
Cables included: AC
Software
Mac operating systems supported: Yes
Operating system installed: DiskStation Manager
Windows operating systems supported: Yes
Storage
RAID support: Yes
RAID levels: JBOD, 10, 1, 0, 6, 5
Hot-swap drive bays: Yes
Supported storage drive types: HDD & SSD
Online RAID migration: Yes
Supported storage drive interfaces: Serial ATA II, Serial ATA III
Supported file systems: ext4, BTRFS, ext3, NTFS, HFS+, Fat, exFAT
Storage drive sizes supported: 3.5", 2.5
Online RAID expansion: Yes
Storage drive capacity: 0 GB
Number of storage drives supported: 8
Total installed storage capacity: 0 TB
Installed storage drive type: No
Storage drives installed: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 4
eSATA ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB port: Yes
PCI Express x8 (Gen 3.x) slots: 1
Other features
Compliance certificates: RoHS, CE
Logistics data
Harmonized System (HS) code: 84714100
Sustainability
Sustainability compliance: Yes
