Processor
Processor model: V1780B
Number of processors supported: 1
Processor manufacturer: AMD
Processor cores: 4
Processor family: Ryzen Embedded
Processor generation: AMD Ryzen Embedded V1000 Series
Processor boost frequency: 3.6 GHz
Processor frequency: 3.35 GHz
Memory
Internal memory: 8 GB
ECC: Yes
Memory slots: 2
Internal memory type: DDR4
Memory form factor: UDIMM
Maximum RAM supported: 32 GB
Design
Built-in speaker(s): No
Chassis type: Rack (2U)
Number of fans: 3 fan(s)
Fan diameter: 6 cm
Cooling type: Active
Product colour: Grey, Black
Built-in display: No
LED indicators: Yes
Power
Redundant power supply (RPS) support: Yes
Power supply location: Built-in
Power supply unit (PSU) capacity: 350 W
Power consumption (typical): 114.86 W
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 0 - 35 °C
Weight & dimensions
Depth: 578 mm
Width: 482 mm
Height: 88 mm
Weight: 11.9 kg
Network
Ethernet LAN: Yes
iSCSI support: Yes
Link aggregation: Yes
Copper ethernet cabling technology: 1000BASE-T, 100BASE-TX, 10BASE-T, 10GBASE-T
Ethernet LAN data rate supported (max): 10000 Mbit/s
Ethernet LAN data rates: 100, 10, 10000 Mbit/s, 1000 Mbit/s
Wake-on-LAN ready: Yes
Performance
Backup function: Yes
Built-in FTP server: Yes
On/off switch: Yes
System log: Yes
Backup features: Cloud, iSCSI LUN
Snapshot: Yes
Multilingual support: Yes
Browser supported: Google Chrome Firefox Microsoft Edge Safari
Noise level: 56.2 dB
Management protocols: SNMP
Device class: Small & Medium Business
Card reader integrated: No
Access Control List (ACL): Yes
Type: NAS
Security algorithms: AES
Packaging content
Cables included: AC
External power adapter: No
Rack mount kit: Yes
Power cables quantity: 2
Software
Operating system installed: DiskStation Manager
Operating system version: 7.1.1
Storage
Supported file systems: ext3, NTFS, HFS+, Fat, exFAT, ext4, BTRFS
Installed storage drive type: No
Number of storage drives supported: 12
Storage drives installed: No
Online RAID migration: Yes
Online RAID expansion: Yes
Storage drive sizes supported: 2.5, 3.5"
Total installed storage capacity: 0 TB
Hot-swap drive bays: Yes
RAID support: Yes
RAID levels: 6, 10, 5, 1, 0, JBOD
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: Serial ATA
Ports & interfaces
USB port: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 3
PCI Express x8 (Gen 3.x) slots: 1
Certification: FCC
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
UL
Other features
Compliance certificates: RoHS, CE
Sustainability
Sustainability compliance: Yes
