Processor
Processor threads: 8
Processor frequency: 2.2 GHz
Processor manufacturer: AMD
Processor generation: AMD Ryzen Embedded V1000 Series
On-board graphics card model: Not available
Processor model: V1500B
Processor cores: 4
Processor family: Ryzen Embedded
Memory
Internal memory type: DDR4
Memory form factor: SO-DIMM
Maximum RAM supported: 32 GB
Internal memory: 2 GB
Design
LED indicators: Power, Alarm, Status
Number of fans: 3 fan(s)
Power
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Operational conditions
Operating temperature (T-T): 0 - 35 °C
Operating altitude: 0 - 5000 m
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 8 - 80%
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Weight: 6.4 kg
Width: 430.5 mm
Height: 44 mm
Depth: 457.6 mm
Network
Wake-on-LAN ready: Yes
Supported network protocols: SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, and VPN (PPTP, OpenVPN™, L2TP)
Performance
Type: NAS
Access Control List (ACL): Yes
Backup function: Yes
On/off switch: Yes
Reset button: Yes
Packaging content
Cables included: AC
Software
Operating system installed: DSM
Storage
Storage drives installed: No
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: Serial ATA
Installed storage drive type: No
Supported file systems: ext3, NTFS, ext4, FAT32, exFAT, HFS+, BTRFS
RAID levels: 10, JBOD, 1, 6, 5, 0
Maximum supported storage capacity: 108 TB
Number of storage drives supported: 4
RAID support: Yes
Hot-swap drive bays: Yes
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
PCI Express x8 (Gen 3.x) slots: 1
eSATA ports quantity: 1
USB port: Yes
Ethernet LAN (RJ-45) ports: 4
