Design Fan diameter: 12 cm Cooling type: Active Illumination: No On/off switch: Yes Product colour: Black Fan location: Top Number of fans: 1 fan(s)
Power Combined power (+3.3V): 80 W Max output current (+12V): 54 A Combined power (-12V): 3.6 W Max output current (+5Vsb): 2.5 A Combined power (+5Vsb): 12.5 W Total power: 650 W Combined power (+5V): 80 W AC input voltage: 200 - 240 V Input current: 7.5 A Power protection features: Short circuit, Over voltage, Over power, Under voltage, Over current Efficiency: 85% Power Factor Correction (PFC) type: Active AC input frequency: 47 - 63 Hz Combined power (+12V): 648 W Max output current (+5V): 10 A Max output current (+3.3V): 10 A Max output current (-12V): 0.3 A
Weight & dimensions Height: 85 mm Weight: 1.36 kg Width: 150 mm Depth: 145 mm
Performance Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS Bronze Noise level: 14 dB Purpose: PC
Packaging data Package width: 126 mm Package height: 203 mm Package type: Box Package weight: 1.51 kg Package depth: 237 mm
Ports & interfaces PCI Express power connectors (6+2 pin): 2 ATX Power connector (24-pin): Yes Number of SATA power connectors: 4 Peripheral (Molex) power connectors (4-pin): 2 Motherboard power connector: 24-pin ATX Cabling type: Non-Modular CPU power connector (4+4 pin): Yes
