Features
Processor frequency: 580 MHz
Flash memory: 16 MB
Internal memory type: DDR2
Processor manufacturer: MediaTek
Processor architecture: MIPS 24Kc
Internal memory: 128 MB
Built-in processor: Yes
Design
LED indicators: LAN, Power, WAN
Product colour: Black
International Protection (IP) code: IP30
Product type: Industrial router
Housing material: Aluminium
Indication light: Yes
Power
Power source type: DC, PoE
Security
Security algorithms: WPA3-EAP, EAP-TLS, SSH, OWE, WPA3-SAE, WPA2-Enterprise-PEAP, AES-CCMP, WPA-PSK, TKIP, WPA2-EAP, WPA2-PSK
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -40 - 70 °C
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Weight: 149.2 g
Depth: 68.6 mm
Height: 25 mm
Width: 113.1 mm
Network
Networking standards: IEEE 802.11g, IEEE 802.11n, IEEE 802.11k, IEEE 802.3az, IEEE 802.3u, IEEE 802.11v, IEEE 802.11s, IEEE 802.11b, IEEE 802.3, IEEE 802.11r
Ethernet LAN data rates: 10, 100
Ethernet LAN interface type: Fast Ethernet
Cabling technology: 10/100Base-T(X)
Auto MDI/MDI-X: Yes
Ethernet LAN: Yes
Full duplex: Yes
Auto-sensing: Yes
Wireless LAN features
Wi-Fi standards: 802.11g, 802.11b, Wi-Fi 4 (802.11n)
Top Wi-Fi standard: Wi-Fi 4 (802.11n)
WLAN data transfer rate (max): 300 Mbit/s
Wi-Fi band: Single-band (2.4 GHz)
Protocols
DHCP client: Yes
DHCP server: Yes
Ports & interfaces
USB 2.0 ports quantity: 1
Ethernet LAN (RJ-45) ports: 2
RS-232 ports: 1
USB port: No
Antenna
Antenna connector type: RP-SMA
Antennas quantity: 1
Antenna design: External
WAN connection
Ethernet WAN: Yes
SIM card slot: No
WAN connection type: RJ-45
DSL WAN: No
3G/4G USB modem compatibility: No
Safety warning
Warnings: The product may emit radio waves that may interfere with other electronic devices., Avoid contact with liquids as this may cause electric shock., Do not open the appliance housing - risk of electric shock.
