Design
Product colour: Black
Housing material: Aluminium
LED indicators: Status, Link, Power
Reset button: No
Stackable: No
Rack mounting: No
Power
Power supply included: No
DC input voltage: 7 - 57 V
Power source: DC
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -40 - 75 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Weight: 280 g
Width: 113.1 mm
Height: 41.2 mm
Depth: 74.6 mm
Network
Networking standards: IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3i
10G support: No
Packaging content
Quick start guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity: 8
Fast Ethernet (copper) ports quantity: 8
Data transmission
MAC address table: 2048 entries
Switching capacity: 20 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE) ports quantity: 8
Power over Ethernet (PoE) voltage: 48 V
Total Power over Ethernet (PoE) budget: 240 W
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) type supported: Active PoE
Safety warning
Warnings: The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Ensure the unit is adequately ventilated during operation., Do not open the case or try to repair it yourself.
