Certification: CE, UKCA, EAC, UCRF, RCM
Features
Built-in processor: Yes
Internal memory: 128 MB
Operating system installed: RutOS
Flash memory: 16 MB
Processor frequency: 580 MHz
Design
Rack mounting: Yes
Housing material: Plastic
Product colour: White
LED indicators: Status
Power
Power source type: DC, PoE
Power over Ethernet (PoE): Yes
Power consumption (typical): 2.5 W
Power consumption (max): 6 W
Security
Firewall: Yes
DoS attack prevention: Yes
ICMP attack prevention: Yes
ARP attack prevention: Yes
Access Control List (ACL): Yes
Security algorithms: HTTPS
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 10 - 90%
Management features
WPS push button: No
Universal Plug and Play (UPnP): Yes
Quality of Service (QoS) support: Yes
Wake-on-LAN ready: Yes
Web-based management: Yes
Reset button: Yes
Firmware upgradeable: Yes
Weight & dimensions
Depth: 235 mm
Width: 100 mm
Height: 49.3 mm
Weight: 855 g
Network
Auto MDI/MDI-X: Yes
Port forwarding: Yes
VLAN support: Yes
Policy-based routing: Yes
Traffic control: Yes
Cabling technology: 10/100Base-T(X)
Static route: Yes
Ethernet interface type: Gigabit Ethernet
Networking standards: IEEE 802.3u, IEEE 802.3az, IEEE 802.3
Packaging content
Manual: Yes
Protocols
Management protocols: FOTA, SSH, SMS, Call, TR-069, MQTT, SNMP, JSON-RPC, RMS
VoIP protocols: H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
DMZ support: Yes
DHCP server: Yes
DHCP client: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
Fast Ethernet (copper) ports quantity: 2
Power over Ethernet (PoE) ports quantity: 2
Antenna
Antennas quantity: 2
Antenna type: Internal
WAN connection
DSL WAN: No
SIM card slot: Yes
Ethernet WAN: Yes
SFP WAN: No
3G/4G USB modem compatibility: No
Other features
Input voltage: 42.5 - 57 V
Mobile network
4G standard: LTE
Short Message Service (SMS): Yes
Mobile network generation: 4G
Safety warning
Warnings: Do not open the appliance housing - risk of electric shock., Avoid contact with liquids as this may cause electric shock., The product may emit radio waves that may interfere with other electronic devices.
