Features
Storage media: Flash
Processor model: MIPS 1004Kc
Built-in processor: Yes
Flash memory: 256 MB
Operating system installed: RutOS
Processor manufacturer: MediaTek
Internal memory type: DDR3
Internal memory: 256 MB
Processor frequency: 880 MHz
Design
LED indicators: Yes
Product colour: Black
Power
Power consumption (typical): 3.9 W
Power consumption (max): 12.3 W
Power plug type: Type E
Power source type: DC
Security
ICMP attack prevention: Yes
Firewall: Yes
Firewall security: Port forward, traffic rules, custom rules
ARP attack prevention: Yes
IP address filtering: Yes
Network address translation (NAT): Yes
Security algorithms: 192-bit AES, 128-bit AES, 256-bit AES, AES, DES
MAC address filtering: Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -40 - 75 °C
Management features
Universal Plug and Play (UPnP): Yes
Reset button: Yes
Firmware upgradeable: Yes
Wake-on-LAN ready: Yes
Web-based management: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Width: 115 mm
Height: 44.2 mm
Depth: 95.1 mm
Weight: 457 g
Network
Port forwarding: Yes
Static route: Yes
VLAN support: Yes
Auto MDI/MDI-X: Yes
Traffic control: Yes
Ethernet interface type: Gigabit Ethernet
Cabling technology: 10/100/1000Base-T(X)
Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u
Ethernet LAN data rates: 100, 1000 Mbit/s, 10
Protocols
Routing protocols: OSPFv2, BGP, RIP-2, EIGRP, NHRP, RIP-1
VoIP protocols: H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
DMZ support: Yes
DHCP server: Yes
DHCP client: Yes
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 4
USB ports quantity: 1
USB version: 2.0
WAN ports quantity: 1
Ethernet LAN (RJ-45) ports: 4
WAN/Ethernet LAN ports quantity: 3
WAN connection
DSL WAN: No
Ethernet WAN: Yes
SIM card slot: Yes
3G/4G USB modem compatibility: No
SFP WAN: No
Mobile network
4G standard: LTE
Short Message Service (SMS): Yes
Mobile network generation: 4G
