Features
Internal memory: 256 MB
Processor model: MIPS 1004Kc
Built-in processor: Yes
Processor manufacturer: MediaTek
Processor frequency: 880 MHz
Storage media: Flash
Operating system installed: RutOS
Internal memory type: DDR3
Flash memory: 256 MB
Design
Product colour: Black
LED indicators: Yes
Power
Power consumption (max): 12.3 W
Power consumption (typical): 3.9 W
Power plug type: Type E
Power source type: DC
Security
ICMP attack prevention: Yes
IP address filtering: Yes
Firewall: Yes
ARP attack prevention: Yes
Firewall security: Port forward, traffic rules, custom rules
MAC address filtering: Yes
Network address translation (NAT): Yes
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Firmware upgradeable: Yes
Quality of Service (QoS) support: Yes
Wake-on-LAN ready: Yes
Reset button: Yes
Web-based management: Yes
Universal Plug and Play (UPnP): Yes
Weight & dimensions
Height: 44.2 mm
Weight: 460 g
Depth: 95.1 mm
Width: 115 mm
Network
Cabling technology: 10/100/1000Base-T(X)
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Auto MDI/MDI-X: Yes
Static route: Yes
Networking standards: IEEE 802.3az, IEEE 802.3u, IEEE 802.3
Traffic control: Yes
VLAN support: Yes
Port forwarding: Yes
Ethernet interface type: Gigabit Ethernet
Protocols
Routing protocols: EIGRP, NHRP, BGP, OSPFv2, RIP-1, RIP-2
DHCP client: Yes
VoIP protocols: H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
DHCP server: Yes
DMZ support: Yes
Ports & interfaces
USB ports quantity: 1
WAN ports quantity: 1
USB version: 2.0
Gigabit Ethernet (copper) ports quantity: 4
Ethernet LAN (RJ-45) ports: 4
WAN connection
DSL WAN: No
3G/4G USB modem compatibility: No
SIM card slot: Yes
SFP WAN: No
Ethernet WAN: Yes
Mobile network
Mobile network generation: 4G
4G standard: LTE
Short Message Service (SMS): Yes
