Features
Processor architecture: MIPS
Built-in processor: Yes
Flash memory: 16 MB
Internal memory: 256 MB
Processor manufacturer: MediaTek
Processor cores: 2
Internal memory type: DDR3
Processor model: MIPS1004KC
Processor frequency: 880 MHz
Design
Product colour: Black
Housing material: Aluminium
International Protection (IP) code: IP30
LED indicators: Link, Power, Status, WAN, WLAN
Indication light: Yes
Product type: Industrial router
Power
Power source type: DC, PoE
Security
Network address translation (NAT): Yes
Security algorithms: WPA2-PSK, OWE, EAP-TLS, WPA-EAP, AES-CCMP, WPA3-EAP, TKIP, WPA3-SAE, WPA-PSK, WPA2-Enterprise-PEAP
DMZ support: Yes
Operational conditions
Operating temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Web-based management: Yes
Reset button: Yes
MU-MIMO technology: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Depth: 95.1 mm
Width: 132 mm
Weight: 560 g
Height: 44.2 mm
VPN support: OpenVPN, OpenVPN Encryption, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard, Tinc, Tailscale
Network
Auto-sensing: Yes
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Cabling technology: 10/100/1000Base-T(X)
Ethernet LAN: Yes
Networking standards: IEEE 802.11r, IEEE 802.11b, IEEE 802.11k, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.11w, IEEE 802.3az, IEEE 802.1x, IEEE 802.3u, IEEE 802.11ac, IEEE 802.11s, IEEE 802.11v, IEEE 802.3
Ethernet LAN interface type: Gigabit Ethernet
Auto MDI/MDI-X: Yes
Load balancing system: Yes
Full duplex: Yes
Packaging content
Antenna included: Yes
Wireless LAN features
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (max): 867 Mbit/s
Wi-Fi standards: 802.11b, Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 5 (802.11ac)
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
Protocols
DHCP client: Yes
DHCP server: Yes
Ports & interfaces
USB port: No
Memory card slot(s): No
Ethernet LAN (RJ-45) ports: 5
Antenna
Antenna connector type: SMA/RP-SMA
Antennas quantity: 11
Antenna design: External
WAN connection
SIM card slot: Yes
DSL WAN: No
WAN connection type: RJ-45, USB
Ethernet WAN: Yes
Mobile network
Dual SIM support: Yes
4G LTE category: 20
5G standard: Sub6 NSA, Sub6 SA, Sub6, NR
Short Message Service (SMS): Yes
SIM card type: MiniSIM
Mobile network generation: 5G
