Features
Internal memory: 256 MB
Processor frequency: 717 MHz
Processor architecture: ARM Cortex A7
Flash memory: 256 MB
Built-in processor: Yes
Design
Product colour: Grey
LED indicators: Power, Status, WLAN
Indication light: Yes
Power
Power source type: DC
Security
Firewall: Yes
Security algorithms: SSH, SSL/TLS
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Management features
Reset button: Yes
Weight & dimensions
Weight: 456 g
Height: 44 mm
Depth: 95 mm
Width: 115 mm
Network
Ethernet LAN: Yes
Ethernet LAN interface type: Gigabit Ethernet
Ethernet LAN data rates: 10, 100, 1000 Mbit/s
Packaging content
Quick installation guide: Yes
Manual: Yes
Quick start guide: Yes
Wireless LAN features
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (max): 867 Mbit/s
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
Protocols
DHCP client: Yes
Supported network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DHCP, DNS, HTTP, HTTPS, SMTP, SSL v3, TLS, ARP, PPPoE, UPNP, SSH, Telnet
Universal Plug and Play (UPnP): Yes
Ports & interfaces
USB 2.0 ports quantity: 1
Ethernet LAN (RJ-45) ports: 4
DC-in jack: Yes
USB port: Yes
Antenna
Antenna design: External
WAN connection
SIM card slot: Yes
WAN connection type: RJ-45
Ethernet WAN: Yes
Logistics data
Harmonized System (HS) code: 85176990
Mobile network
4G: Yes
Mobile network generation: 4G
4G standard: LTE
3G standards: DC-HSDPA, WCDMA
3G: Yes
