Features
Antenna connector type: SMA
Antennas quantity: 1
Short Message Service (SMS): Yes
Antenna type: External
Design
International Protection (IP) code: IP30
Enclosure material: Aluminium
Enclosure International Protection (IP) code: IP30
Product colour: Steel
Power
Power consumption (typical): 3 W
Power consumption (max): 6 W
Power over Ethernet (PoE): Yes
DC input voltage: 12 – 30
Security
VLAN support: Yes
Firewall security: Yes
Network address translation (NAT): Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -40 - 75 °C
Management features
Quality of Service (QoS) support: Yes
Weight & dimensions
Depth: 73 mm
Width: 74.5 mm
Weight: 145 g
Height: 25 mm
Network
Dynamic DNS (DDNS): Yes
Cabling technology: 10/100/1000Base-T(X)
Data network: 4G, 2G, 3G
Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u
Mobile network generation: 4G
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
4G LTE category: 4
Performance
Control display unit: No
Processor manufacturer: ARM
Processor family: ARM Cortex
Built-in processor: Yes
Internal memory: 256 MB
Internal memory type: DDR3
Processor frequency: 1300 MHz
Flash memory: 512 MB
Processor model: Cortex-A7
Protocols
DMZ support: Yes
Data link protocols: HTTP(S), MQTT, Azure MQTT, Kinesis
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
WAN connection: Ethernet (RJ-45)
