Design
LED indicators: Power
Product colour: Grey
Security
Network address translation (NAT): Yes
VLAN support: Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -40 - 75 °C
Management features
Reset button: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Depth: 25 mm
Height: 74 mm
Width: 83 mm
Weight: 165 g
Network
Ethernet LAN data rates: 10, 100
Networking standards: IEEE 802.3u, IEEE 802.3
Forwarding rate: 150 Mpps
Certification: CE/RED, EAC, RoHS, WEEE
Draft ETSI EN 301 489-1 V2.2.0, Draft EN 301 489-19 V2.1.0, Draft ETSI EN 301 489-52 V1.1.0
EN 61000-4-2:2009
EN 300 511 V12.5.1, ETSI EN 301 908-1 V11.1.1, ETSI EN 301 908-2 V11.1.2, ETSI EN 301 908-13 V11.1.2
EN 61000-4-3:2006 + A1:2008 + A2:2010
EN 61000-4-4:2012
EN 61000-4-5:2014
EN 61000-4-6:2014
EN 61000-4-11:2004
Certificates
Safety: IEC 62368-1:2014, EN 50385:2017, EN 62232:2017
Protocols
DMZ support: Yes
Management protocols: SNMP
Ports & interfaces
Serial interface type: RS-232/485
Console port: RS-232
SIM card slot: Yes
RS-232 ports: 1
Ethernet LAN (RJ-45) ports: 1
Logistics data
Harmonized System (HS) code: 85176990
Safety warning
Warnings: Do not open the appliance housing - risk of electric shock., The product may emit radio waves that may interfere with other electronic devices., Avoid contact with liquids as this may cause electric shock.
