Design
Mounting: DIN-rail/Wall mounting
LED indicators: LAN, Status, Power, Signal strength
Housing material: Aluminium
Product colour: Black
Device type: Cellular network gateway
Market positioning: Industrial
Suitable for indoor use: Yes
Power
Power source type: DC
Input voltage: 9 - 30 V
External power adapter: Yes
Security
Port forwarding: Yes
DMZ support: Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -40 - 75 °C
Management features
Management platform: RMS
Weight & dimensions
Depth: 74.2 mm
Weight: 165 g
Height: 25 mm
Width: 83 mm
Performance
Antenna connector type: SMA
Built-in processor: Yes
Antennas quantity: 2
Processor manufacturer: MediaTek
Web-based management: Yes
Antenna type: External
Processor frequency: 0.58 GHz
RAM capacity: 0.128 GB
RAM type: DDR2
GPS (satellite): Yes
Internal storage capacity: 0.016 GB
Wireless LAN features
Wi-Fi: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Serial ports quantity: 1
Serial interface type: RS-232, RS-232/485
GPS Performance
Embedded GNSS: Yes
Quasi-Zenith Satellite System (QZSS): Yes
Galileo: Yes
BeiDou: Yes
GLONASS: Yes
Mobile network
SIM interface: 3 V
Short Message Service (SMS): Yes
SIM card type: MiniSIM
Number of SIM cards: 2
Data network: 2G, 3G, LTE, 4G
Data transfer rate (LTE) (upload): 50 Mbit/s
Data transfer rate (LTE) (download): 150 Mbit/s
Ethernet LAN features
Ethernet LAN data rates: 10, 100
Networking standards: IEEE 802.3az, IEEE 802.11e, IEEE 802.3u, IEEE 802.3
Ethernet LAN: Yes
Auto MDI/MDI-X: Yes
DHCP server: Yes
Ethernet LAN interface type: Fast Ethernet
Full duplex: Yes
Serial interface
RS-232 signals: CTS, Rx, RTS, Tx
RS-485 signals: Data-, RDB+, Data+, RDA-
