Features
Antenna type: External
Antenna connector type: SMA
Antennas quantity: 4
Short Message Service (SMS): Yes
Design
Enclosure material: Aluminum
LED indicators: Status, Power, Signal strength, LAN
Product colour: Stainless steel
International Protection (IP) code: IP30
Mounting type: DIN-rail/Wall mounting
Power
DC input voltage: 9 - 30 V
Power consumption (max): 6 W
Security
MAC address filtering: Yes
Network address translation (NAT): Yes
DoS attack prevention: Yes
VLAN support: Yes
Firewall security: Yes
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Reset button: Yes
Web-based management: Yes
Syslog: Yes
Weight & dimensions
Weight: 241 g
Depth: 93.4 mm
Width: 100 mm
Height: 30 mm
Network
Ethernet LAN data rates: 100, 1000 Mbit/s, 10
Dynamic DNS (DDNS): Yes
Cabling technology: 10/100/1000Base-T(X)
Performance
Processor frequency: 1500 MHz
Control display unit: No
Internal memory: 256 MB
Built-in processor: Yes
Flash memory: 512 MB
Packaging content
Quick start guide: Yes
AC adapter included: Yes
Cables included: Micro-USB, LAN (RJ-45)
Protocols
Supported network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SMTP, SSL v3, TLS, PPP, PPPoE, SSH, DHCP, SNMP, MQTT, Wake on LAN (WOL)
Routing protocols: RIP-1, OSPFv2, RIP-2, BGP, EIGRP, NHRP
Ports & interfaces
SIM card type: MiniSIM
SIM card slot: Yes
Number of simultaneous SIM cards: 1
Ethernet LAN (RJ-45) ports: 1
