Design
Product colour: Black
Wall mountable: Yes
International Protection (IP) code: IP30
LED indicators: Yes
Housing material: Aluminium
DIN rail mounting: Yes
Power
Power source: DC
DC input voltage: 7 - 57 V
Power supply included: No
Power consumption (max): 5.5 W
Operational conditions
Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 5 - 95%
Management features
Switch type: Unmanaged
Weight & dimensions
Height: 44.2 mm
Depth: 95.1 mm
Weight: 517 g
Width: 132 mm
Network
Networking standards: IEEE 802.3x, IEEE 802.3at, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u
Auto MDI/MDI-X: Yes
10G support: No
Packaging data
Package type: Box
Packaging content
Quick start guide: Yes
Certificates
Compliance certificates: CB, Industry Canada (IC), Federal Communications Commission (FCC), CE, UKCA
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Power connector: DC-in jack
SFP module slots quantity: 2
Data transmission
MAC address table: 2000 entries
Switching capacity: 20 Gbit/s
Packet buffer memory: 0.128 MB
Jumbo frames: 9216
Jumbo frames support: Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 240 W
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet plus (PoE+) ports quantity: 8
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) type supported: PoE+, Active PoE
Power over Ethernet (PoE) modes: Alternative B, Alternative A
