Design
LED indicators: LAN, Power
Reset button: Yes
International Protection (IP) code: IP30
Product colour: Black
Power
Power source: DC
Power supply included: No
Power consumption (max): 6 W
Security
Security algorithms: SNMPv3, SNMPv2
DHCP features: DHCP client, DHCP server
Queue scheduling algorithms: Weighted Round Robin (WRR), WFQ, WFQ+SP
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -40 - 75 °C
Management features
Quality of Service (QoS) support: Yes
Switch type: Managed
Switch layer: L2
Weight & dimensions
Depth: 122.2 mm
Width: 132 mm
Height: 44.2 mm
Weight: 615 g
Network
Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3az
Port mirroring: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
10G support: No
Auto MDI/MDI-X: Yes
VLAN support: Yes
IP routing: Yes
Performance
Internal memory: 128 MB
Memory type: DDR3-SDRAM
Flash memory: 16 MB
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 8
SFP module slots quantity: 2
Data transmission
MAC address table: 8000 entries
Jumbo frames support: Yes
Switching capacity: 20 Gbit/s
Jumbo frames: 10000
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
