Features
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
Maximum data transfer rate (2.4 GHz): 300 Mbit/s
Networking standards: IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11a, IEEE 802.11b
Bandwidth: 24 GHz
Wi-Fi Multimedia (WMM)/(WME): Yes
2.4 GHz: Yes
5 GHz: Yes
Maximum data transfer rate (5 GHz): 867 Mbit/s
VLAN support: Yes
Design
Product colour: White
Placement: Ceiling, Wall
LED indicators: System
Reset button: Yes
Power
Power consumption (max): 11.5 W
Power over Ethernet (PoE): Yes
Output voltage: 12 V
Output current: 1 A
Security
Security algorithms: WPA2, WPA, WEP, WPA-PSK, WPA2-PSK
MAC address filtering: Yes
Operational conditions
Storage temperature (T-T): -30 - 70 °C
Operating temperature (T-T): -10 - 45 °C
Storage relative humidity (H-H): 10 - 90%
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Height: 38 mm
Width: 178 mm
Depth: 178 mm
Protocols
DHCP client: Yes
DHCP server: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Antenna
Antennas quantity: 2
Antenna gain level (max): 2 dBi
Logistics data
Harmonized System (HS) code: 85176990
