Certification: CCC, SRRC, CE, FCC, RoHs
Technical details
Reset button: Yes
Video compression formats: H.264, H.265
Power
Power source type: DC
DC output current: 2 A
DC output voltage: 12
Weight & dimensions
Recorder width: 20 cm
Camera depth: 7.2 cm
Camera weight: 226 g
Recorder depth: 20 cm
Recorder height: 4.8 cm
Camera width: 17.5 cm
Camera height: 7.2 cm
Recorder weight: 510 g
Network
Wi-Fi standards: 802.11g, 802.11b, Wi-Fi 4 (802.11n)
Frequency band: 2.4 GHz
Wi-Fi data rate (max): 144 Mbit/s
Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet
Wi-Fi: Yes
Packaging content
Quick installation guide: Yes
Mounting kit: Yes
Power supply included: Yes
Mouse included: Yes
Supported resolutions: 2304 ×1296, 1920 × 1080, 1280 × 720, 640 × 360, 352 × 288
Camera
Connectivity technology: Wired & Wireless
Viewing angle, vertical: 46°
Built-in microphone: Yes
Viewing angle, horizontal: 86.1°
International Protection (IP) code: IP66
LED type: IR
Night vision distance: 30 m
Night mode: Yes
Colour: Yes
Viewing angle, diagonal: 104°
Rotating: No
Camera included: Yes
Sensor type: CMOS
Fixed focal length: 4 mm
Camera interface: Wi-Fi/RJ-45
Heat function: No
Surveillance camera form factor: Bullet
Placement supported: Outdoor
Camera resolution: 2304 x 1296 pixels
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Number of illumination LEDs: 2
Playback resolutions supported: 1920 × 1080, 1280 × 1024, 1280 × 720
Recorder
LED indicators: Yes
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 1
HDD interface: SATA III
Card reader integrated: No
Supported network protocols: TCP/IP, IPv4, RTSP, UDP, NTP, DHCP
Storage media type: Not available
Channels quantity: 4 channels
Recorder included: Yes
Maximum HDD capacity: 10 TB
Number of HDDs supported: 1
