Design
Mounting type: Wall/Ceiling
Product colour: White
Power
DC output current: 1 A
DC output voltage: 12V
Power source type: Power socket
Security
Video motion detection: Yes
Intelligent Video Surveillance (IVS) system features: Human detection
Operational conditions
Operating relative humidity (H-H): 10 - 95%
Operating temperature (T-T): -40 - 60 °C
Weight & dimensions
Width: 80 mm
Depth: 76 mm
Height: 80 mm
Weight: 307 g
Network
Ethernet interface type: 10 Megabit Ethernet, 100 Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi: No
Onvif standard: Yes
Bluetooth: No
Performance
Infrared (IR) cut-off filter: Yes
Wide Dynamic Range (WDR): Yes
Day/night mode: Yes
Type: Sensor camera
Placement supported: Outdoor
Built-in light: Yes
Connectivity technology: Wired
Packaging content
Manual: Yes
AC adapter included: Yes
Number of cameras: 1
Screws included: Yes
Drilling template included: Yes
Quick start guide: Yes
Audio
Built-in speaker(s): No
Built-in microphone: Yes
Audio system: Mono
Storage
Built-in HDD: No
Ports & interfaces
USB powered: No
Ethernet LAN (RJ-45) ports: 1
Camera
Pan range: 0 - 360°
Lens viewing angle, horizontal: 79.1°
Lens viewing angle, diagonal: 94.9°
Tilt angle range: 0 - 78°
Lens viewing angle, vertical: 43.3°
Image sensor
Sensor type: CMOS
Progressive scan: Yes
Number of sensors: 1
Video
Video streaming: Yes
Video compression formats: H.265+, H.264, H.265
Digital Wide Dynamic Range (DWDR): Yes
Video formats supported: H.265+, H.265, H.264
Frame rate: 30 fps
Maximum resolution: 2560 x 1440 pixels
Night vision
Night vision distance: 30 m
Night vision: Yes
Lens system
Maximum aperture number: 1.6
Number of lenses: 1
Fixed focal length: 4 mm
Safety warning
Warnings: Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling., The product contains electronic components; do not dispose of with the normal household waste.
Sustainability
Sustainability compliance: Yes
Compliance certificates: UKCA, Federal Communications Commission (FCC), RoHS, CE
