Design
Product colour: White
Mounting type: Wall/Ceiling
Power
Power source type: Power socket
DC output current: 1 A
DC output voltage: 12V
Security
Video motion detection: Yes
Intelligent Video Surveillance (IVS) system features: Human detection
Operational conditions
Operating relative humidity (H-H): 10 - 95%
Operating temperature (T-T): -40 - 60 °C
Weight & dimensions
Width: 80 mm
Depth: 76 mm
Weight: 307 g
Height: 80 mm
Network
Bluetooth: No
Ethernet LAN: Yes
Ethernet interface type: 10 Megabit Ethernet, 100 Gigabit Ethernet
Wi-Fi: No
Onvif standard: Yes
Performance
Wide Dynamic Range (WDR): Yes
Built-in light: Yes
Type: Sensor camera
Connectivity technology: Wired
Placement supported: Outdoor
Day/night mode: Yes
Infrared (IR) cut-off filter: Yes
Packaging content
Quick start guide: Yes
Manual: Yes
Number of cameras: 1
AC adapter included: Yes
Screws included: Yes
Drilling template included: Yes
Audio
Built-in microphone: Yes
Audio system: Mono
Built-in speaker(s): No
Storage
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
USB powered: No
Camera
Tilt angle range: 0 - 78°
Pan range: 0 - 360°
Lens viewing angle, vertical: 43.3°
Lens viewing angle, diagonal: 94.9°
Lens viewing angle, horizontal: 79.1°
Image sensor
Sensor type: CMOS
Number of sensors: 1
Progressive scan: Yes
Video
Maximum resolution: 2560 x 1440 pixels
Digital Wide Dynamic Range (DWDR): Yes
Video formats supported: H.264, H.265, H.265+
Video compression formats: H.265, H.264, H.265+
Video streaming: Yes
Frame rate: 30 fps
Night vision
Night vision distance: 30 m
Night vision: Yes
Lens system
Maximum aperture number: 1.6
Fixed focal length: 6 mm
Number of lenses: 1
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling.
Sustainability
Compliance certificates: RoHS, CE, Federal Communications Commission (FCC), UKCA
Sustainability compliance: Yes
