Design
Product colour: White
Mounting type: Desk/Ceiling
Form factor: Dome
Power
Power source type: Power socket
DC output current: 1 A
DC output voltage: 12V
Security
Video motion detection: Yes
Intelligent Video Surveillance (IVS) system features: Human detection
Operational conditions
Operating relative humidity (H-H): 10 - 95%
Operating temperature (T-T): -40 - 60 °C
Weight & dimensions
Depth: 76 mm
Width: 80 mm
Weight: 307 g
Height: 80 mm
Network
Bluetooth: No
Ethernet interface type: 10 Megabit Ethernet, 100 Gigabit Ethernet
Ethernet LAN: Yes
Onvif standard: Yes
Wi-Fi: No
Performance
Infrared (IR) cut-off filter: Yes
Day/night mode: Yes
Built-in light: Yes
Placement supported: Outdoor
Wide Dynamic Range (WDR): Yes
Type: Sensor camera
Connectivity technology: Wired
Packaging content
Quick start guide: Yes
Manual: Yes
Screws included: Yes
Drilling template included: Yes
AC adapter included: Yes
Number of cameras: 1
Audio
Built-in speaker(s): No
Built-in microphone: Yes
Audio system: Mono
Storage
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
USB powered: No
Camera
Tilt angle range: 0 - 78°
Pan range: 0 - 360°
Lens viewing angle, horizontal: 82.91°
Lens viewing angle, vertical: 46,2°
Lens viewing angle, diagonal: 97,3°
Image sensor
Progressive scan: Yes
Number of sensors: 1
Sensor type: CMOS
Video
Video formats supported: H.264, H.265, H.265+
Video compression formats: H.265+, H.264, H.265
Frame rate: 30 fps
Video streaming: Yes
Maximum resolution: 2560 x 1440 pixels
Digital Wide Dynamic Range (DWDR): Yes
Night vision
Night vision: Yes
Night vision distance: 30 m
Lens system
Maximum aperture number: 1.6
Fixed focal length: 2.8 mm
Number of lenses: 1
Safety warning
Warnings: Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling., The product contains electronic components; do not dispose of with the normal household waste.
Sustainability
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE, UKCA
Sustainability compliance: Yes
