Design
Product colour: White
Form factor: Dome
Mounting type: Desk/Ceiling
Power
Power source type: Power socket
DC output current: 1 A
DC output voltage: 12V
Security
Intelligent Video Surveillance (IVS) system features: Human detection
Video motion detection: Yes
Operational conditions
Operating temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 10 - 95%
Weight & dimensions
Weight: 307 g
Depth: 76 mm
Height: 80 mm
Width: 80 mm
Network
Bluetooth: No
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: 100 Gigabit Ethernet, 10 Megabit Ethernet
Onvif standard: Yes
Performance
Built-in light: Yes
Connectivity technology: Wired
Day/night mode: Yes
Wide Dynamic Range (WDR): Yes
Type: Sensor camera
Placement supported: Outdoor
Infrared (IR) cut-off filter: Yes
Packaging content
Quick start guide: Yes
Screws included: Yes
Drilling template included: Yes
AC adapter included: Yes
Number of cameras: 1
Manual: Yes
Audio
Built-in microphone: Yes
Audio system: Mono
Built-in speaker(s): No
Storage
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
USB powered: No
Camera
Lens viewing angle, horizontal: 79.1°
Lens viewing angle, vertical: 43.3°
Lens viewing angle, diagonal: 94.9°
Tilt angle range: 0 - 78°
Pan range: 0 - 360°
Image sensor
Sensor type: CMOS
Progressive scan: Yes
Number of sensors: 1
Video
Video compression formats: H.265, H.264, H.265+
Frame rate: 30 fps
Video formats supported: H.265+, H.264, H.265
Maximum resolution: 2560 x 1440 pixels
Digital Wide Dynamic Range (DWDR): Yes
Video streaming: Yes
Night vision
Night vision distance: 30 m
Night vision: Yes
Lens system
Maximum aperture number: 1.6
Fixed focal length: 4 mm
Number of lenses: 1
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling.
Sustainability
Sustainability compliance: Yes
Compliance certificates: RoHS, CE, UKCA, Federal Communications Commission (FCC)
