Design
LED indicators: Activity, PoE, Power, Link
Product colour: Black
Wall mountable: Yes
Power
Power consumption (typical): 120 W
Power source: DC/PoE
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Operational conditions
Operating temperature (T-T): 0 - 45 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Management features
Switch type: Unmanaged
Weight & dimensions
Depth: 104 mm
Height: 26 mm
Width: 177.5 mm
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x, IEEE 802.3at
Cable types supported: Cat5, Cat5e
10G support: No
Performance
Mean time between failures (MTBF): 100000 h
Ports & interfaces
SFP module slots quantity: 1
Basic switching RJ-45 Ethernet ports quantity: 9
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Data transmission
Forwarding rate: 14.9 Mpps
Switching capacity: 20 Gbit/s
Store-and-forward: Yes
MAC address table: 8000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 15.4 W
Total Power over Ethernet (PoE) budget: 92 W
Power over Ethernet (PoE) ports quantity: 8
Power over Ethernet (PoE): Yes
