Design
Product colour: Black
Product type: Tabletop router
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Output current: 1 A
Output voltage: 12 V
Power source type: AC
Security
DMZ support: Yes
Firewall: Yes
Parental control: Yes
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 5 - 90%
Management features
WPS push button: Yes
Reset button: Yes
Web-based management: Yes
Weight & dimensions
Depth: 56 mm
Height: 200 mm
Width: 244 mm
Network
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
VPN server: PPTP
Ethernet LAN: Yes
Cabling technology: 10/100/1000Base-T(X)
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN interface type: Gigabit Ethernet
Dynamic DNS (DDNS): Yes
Packaging content
Quick installation guide: Yes
AC adapter included: Yes
Cables included: LAN (RJ-45)
Wireless LAN features
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi standards: 802.11g, Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 4 (802.11n)
WLAN data transfer rate (second band): 1201 Mbit/s
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (first band): 300 Mbit/s
WLAN data transfer rate (max): 1201 Mbit/s
Certificates
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE
Protocols
DHCP client: Yes
Supported network protocols: IPv4, IPv6
DHCP server: Yes
Universal Plug and Play (UPnP): Yes
Ports & interfaces
DC-in jack: Yes
USB port: No
Ethernet LAN (RJ-45) ports: 4
Antenna
Antenna design: External
Antennas quantity: 5
WAN connection
Ethernet WAN: Yes
DSL WAN: No
3G/4G USB modem compatibility: No
SIM card slot: No
