Design
On/off switch: Yes
Product colour: Black
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Power
Power protection features: Short circuit, Over voltage, Overheating, Under voltage, Over current, Over power
AC input voltage: 100 - 240 V
Combined power (+5V): 105 W
Total power: 600 W
Max output current (+5V): 16 A
Max output current (+5Vsb): 3 A
Input current: 12 - 5 A
Combined power (+5Vsb): 15 W
Hold time: 17 ms
Max output current (-12V): 0.3 A
Power Factor Correction (PFC) type: Active
AC input frequency: 50/60 Hz
Combined power (+3.3V): 105 W
Combined power (-12V): 3.6 W
Combined power (+12V): 600 W
Max output current (+3.3V): 16 A
Max output current (+12V): 50 A
Operational conditions
Operating relative humidity (H-H): 20 - 85%
Storage temperature (T-T): -40 - 55 °C
Operating temperature (T-T): 5 - 40 °C
Storage relative humidity (H-H): 10 - 95%
Weight & dimensions
Width: 150 mm
Depth: 140 mm
Height: 86 mm
Performance
80 PLUS certification: 80 PLUS
Mean time between failures (MTBF): 100000 h
ATX version: 3.1
Bearing technology: FDB
Power supply unit (PSU) form factor: ATX
Purpose: PC
Packaging data
Package type: Box
Ports & interfaces
Peripheral (Molex) power connectors (4-pin): 4
EPS power connector (4+4 pin): Yes
Number of SATA power connectors: 4
SATA power cable length: 800 mm, 500 mm, 650, 950 mm
Motherboard power connector: 24-pin ATX
ATX Power connector (24-pin): Yes
PCI Express power connectors (6+2 pin): 2
Peripheral (Molex) power cable length: 950 mm, 500 mm, 800, 650
PCI Express power cable length: 65 cm
Cabling type: Non-Modular
Motherboard power cable length: 60 cm
