Design
Fan diameter: 12 cm
Number of fans: 1 fan(s)
On/off switch: Yes
Product colour: Black
Power
Max output current (+5V): 18 A
Combined power (+5Vsb): 15 W
Combined power (+5V): 110 W
Hold time: 17 ms
Combined power (-12V): 3.6 W
Max output current (+12V): 58.33 A
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 110 W
Combined power (+12V): 700 W
Total power: 700 W
Power protection features: Over power, Short circuit, Over voltage, Overheating, Under voltage, Over current
Max output current (+5Vsb): 3 A
Max output current (-12V): 0.3 A
Max output current (+3.3V): 18 A
AC input voltage: 100 - 240 V
Input current: 12 - 6 A
AC input frequency: 50/60 Hz
Operational conditions
Operating relative humidity (H-H): 20 - 85%
Operating temperature (T-T): 5 - 40 °C
Storage relative humidity (H-H): 10 - 95%
Storage temperature (T-T): -40 - 55 °C
Weight & dimensions
Depth: 140 mm
Width: 150 mm
Height: 86 mm
Performance
80 PLUS certification: 80 PLUS
Mean time between failures (MTBF): 100000 h
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
Bearing technology: FDB
Packaging data
Package type: Box
Ports & interfaces
SATA power cable length: 800 mm, 500 mm, 650, 950 mm
Number of SATA power connectors: 4
Motherboard power cable length: 60 cm
Cabling type: Non-Modular
EPS power connector (4+4 pin): Yes
Motherboard power connector: 24-pin ATX
PCI Express power connectors (6+2 pin): 2
PCI Express power cable length: 65 cm
Peripheral (Molex) power connectors (4-pin): 4
ATX Power connector (24-pin): Yes
Peripheral (Molex) power cable length: 800, 500 mm, 950 mm, 650
