Design On/off switch: Yes Product colour: Black Fan diameter: 12 cm Number of fans: 1 fan(s) Cooling type: Active
Power Max output current (+5Vsb): 3 A Power Good signal delay range: 100 - 250 ms Max output current (-12V): 0.3 A Combined power (-12V): 3.6 W Combined power (+5V): 100 W Combined power (+5Vsb): 15 W AC input voltage: 100 - 240 V Total power: 750 W Power protection features: Overheating, Over power, Under voltage, Over current, Short circuit, Over voltage Hold time: 17 ms Max output current (+5V): 20 A Combined power (+12V): 750 W Input current: 10 A Max output current (+12V): 62.5 A Combined power (+3.3V): 100 W Power Factor Correction (PFC) type: Active Max output current (+3.3V): 20 A AC input frequency: 50/60 Hz
Operational conditions Storage temperature (T-T): -40 - 70 °C Storage relative humidity (H-H): 5 - 95% Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 5 - 85%
Weight & dimensions Depth: 140 mm Height: 86 mm Width: 150 mm
Performance Mean time between failures (MTBF): 100000 h Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS Gold Purpose: PC/Server ATX version: 3.1 Bearing technology: Hydraulic
Packaging data Package type: Box
Ports & interfaces Peripheral (Molex) power cable length: 150, 400 mm PCI Express power connectors (12+4 pin) cable length: 600 mm Motherboard power connector: 24-pin ATX CPU power connector (4+4 pin): Yes Number of SATA power connectors: 6 CPU power cable length: 70 cm PCI Express power connectors (12+4 pin): 1 PCI Express power connectors (6+2 pin): 4 Peripheral (Molex) power connectors (4-pin): 4 Cabling type: Fully-Modular SATA power cable length: 150, 450 Motherboard power cable length: 55 cm
