Design On/off switch: Yes Fan diameter: 12 cm Number of fans: 1 fan(s) Cooling type: Active Product colour: Black
Power Max output current (+5Vsb): 2.5 A Max output current (-12V): 0.3 A Total power: 550 W Combined power (+12V): 550 W Max output current (+12V): 45.8 A Combined power (+3.3V): 100 W Max output current (+5V): 18 A Power Factor Correction (PFC) type: Active Power protection features: Overheating, Over power, Under voltage, Over current, Short circuit, Over voltage Combined power (-12V): 3.6 W Combined power (+5Vsb): 12.5 W Hold time: 17 ms Combined power (+5V): 100 W Max output current (+3.3V): 18 A AC input frequency: 50 Hz Input current: 8 A AC input voltage: 200 - 240 V
Operational conditions Storage relative humidity (H-H): 10 - 95% Operating relative humidity (H-H): 20 - 85% Operating temperature (T-T): 5 - 40 °C Storage temperature (T-T): -40 - 55 °C
Weight & dimensions Height: 86 mm Depth: 140 mm Width: 150 mm
Performance Bearing technology: Hydraulic Purpose: PC/Server Power supply unit (PSU) form factor: ATX Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS
Packaging data Package type: Box
Ports & interfaces Motherboard power connector: 20+4 pin ATX Number of SATA power connectors: 4 PCI Express power cable length: 50 cm CPU power cable length: 65 cm Motherboard power cable length: 60 cm Peripheral (Molex) power connectors (4-pin): 4 PCI Express power connectors (6+2 pin): 2 Cabling type: Non-Modular Peripheral (Molex) power cable length: 500 mm CPU power connector (4+4 pin): Yes SATA power cable length: 500 mm
