Features
Windows operating systems supported: Windows 2000, Windows 10, Windows 8.1, Windows Vista, Windows 98SE, Windows XP, Windows 8, Windows NT, Windows 7
Mac operating systems supported: Yes
Flash memory: 128 MB
Internal memory type: DDR4
Linux operating systems supported: Yes
Internal memory: 512 MB
Design
Rack mounting: Yes
Product colour: Black
Power
AC input voltage: 100 - 240 V
Power consumption (max): 7.5 W
AC input frequency: 50/60 Hz
Security
URL filtering: Yes
Security algorithms: SHA-1, 192-bit AES, DES, 128-bit AES, SHA-384, SHA-2, SHA-512, MD5, 256-bit AES
DoS attack prevention: Yes
VPN tunnels quantity: 50
ARP attack prevention: Yes
ICMP attack prevention: Yes
Operational conditions
Storage relative humidity (H-H): 5 - 90%
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Management features
Reset button: Yes
Web-based management: Yes
Weight & dimensions
Depth: 140 mm
Height: 44 mm
Width: 294 mm
Network
Ethernet LAN data rates: 1000, 100 Mbit/s, 10
VLAN support: Yes
Static route: Yes
Networking standards: IEEE 802.3x, IEEE 802.1D, IEEE 802.3z, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet interface type: Gigabit Ethernet
Packaging content
Cables included: AC
Quick installation guide: Yes
Certificates
Compliance certificates: RoHS, CE, Federal Communications Commission (FCC)
Protocols
DMZ support: Yes
DHCP server: Yes
Ports & interfaces
Installed SFP modules quantity: 1
USB ports quantity: 1
Ethernet LAN (RJ-45) ports: 5
WAN connection
SFP WAN: Yes
3G/4G USB modem compatibility: Yes
SIM card slot: No
DSL WAN: No
Ethernet WAN: Yes
Safety warning
Warnings: Ensure the unit is adequately ventilated during operation., Do not open the case or try to repair it yourself., The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations.
