Design
Product colour: Black
Product type: Tabletop router
Power
Power source type: DC
Output current: 1 A
Output voltage: 12 V
NAT functionality: ALG, Virtual Server, Port Trigger, DMZ, uPnP
Security
Security algorithms: SSID, WPA2, WPA3, IPSec, WPA
Network address translation (NAT): Yes
Parental control: Yes
Firewall: Yes
DMZ support: Yes
Operational conditions
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 60 °C
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Quality of Service (QoS) support: Yes
Reset button: Yes
MU-MIMO technology: Yes
WPS push button: Yes
Weight & dimensions
Depth: 94 mm
Width: 182.7 mm
Height: 33.3 mm
VPN support: IPSec, PPTP, L2TP
Network
Ethernet LAN data rates: 100, 1000 Mbit/s, 10
Ethernet LAN: Yes
Cabling technology: 10/100/1000Base-T(X)
Ethernet LAN interface type: Gigabit Ethernet
Dynamic DNS (DDNS): Yes
Port forwarding: Yes
Port triggering: Yes
VPN Passthrough: Yes
VPN server: PPTP, OpenVPN, IPSec
System requirements
Linux operating systems supported: Yes
Mac operating systems supported: Yes
Windows operating systems supported: Yes
Browser supported: Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 browers or higher
Packaging content
Quick installation guide: Yes
AC adapter included: Yes
Cables included: LAN (RJ-45)
Wireless LAN features
Modulation: 1024-QAM
Wi-Fi standards: 802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11g
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max): 1201 Mbit/s
WLAN data transfer rate (second band): 1201 Mbit/s
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (first band): 300 Mbit/s
Protocols
DHCP client: Yes
DHCP server: Yes
Management protocols: TR-069, TR-098, TR-181, TR-111, and TR-143
Ports & interfaces
USB port: No
Ethernet LAN (RJ-45) ports: 4
Antenna
Antennas quantity: 4
Antenna design: External
WAN connection
Ethernet WAN: Yes
3G/4G USB modem compatibility: No
WAN connection type: RJ-45
SIM card slot: No
